Remote Low Height Three-Section Freezer

Model # | Description |
---|---|
LHF-90-3D | 90" Wide, Three Drawers, 6 Pans Front-to-Back |
LHF-90T-3D | 90" Wide, Three Drawers, 6 Pans Front-to-Back |
LHF-96-3D | 96" Wide, Three Drawers, 6 Pans FB/SBS |
LHF-96T-3D | 96" Wide, Three Drawers, 6 Pans FB/SBS |
LHF-102-3D | 102" Wide, Three Drawers, 6 Pans Side-by-Side |
LHF-102T-3D | 102" Wide, Three Drawers, 6 Pans Side-by-Side |

- Modular design allows for side-by-side line up of cabinets
- Stainless steel front, sides and self-closing drawers
- Rugged drawer construction
- Integral one-piece stainless steel drawer pull
- Snap-in magnetic gaskets
- Coved corner stainless steel interior
- Adjustable 6" stainless steel legs or 6" casters in lieu of legs
- Utilities pre-plumbed with stub outs on left side (optional on right side)
- Heavy-duty built-in security cylinder door lock
- Concealed condensate heaters around each opening
- Self-closing door hinges with stay-open feature at 120 degrees (std.
door hinging is left door hinged left, center and right doors hinged
right; other configurations available) - Expansion valve refrigeration system
- Reinforced top to support heavy restaurant equipment
- Specially insulated top for efficient cooling when used with
cooking equipment - Low cabinet height places cooking equipment at ergonomically
convenient level - Condensate evaporator
- R-404a refrigerant for superior temperature recovery and pulldown
- Impact-resistant PVC breaker strip
- 5 year parts, 1 year labor warranty

Rugged drawer construction

Adjustable 6" stainless steel legs or 6" casters in lieu of legs
- Stainless steel top (specify equipment flat, or marine edge type)
- Stainless steel back ___ and/or bottom___ (specify either or both)
- Marine secure latch
- Door in lieu of drawers (specify hinging)
- Drawer locking hasp
- Additional chrome wire shelves (specify quantity)_____
- Stainless steel wire shelves in lieu of chrome
- Thermostat & solenoid
- Condensing unit (air or water-cooled; please specify)
- Alternate locations for refrig/elec/drain stub outs (please specify)
- 6" front locking casters in lieu of legs (no charge)
- 6" seismic legs
- Correctional facilities package
- Custom modifications (please specify)

6" seismic legs

Stainless steel top options
PRODUCT DATA Data is for Std Models; Options may change specifications | LHF-90-3D | LHF-90T-3D | LHF-96-3D | LHF-96T-3D | LHF-102-3D | LHF-102T-3D |
---|---|---|---|---|---|---|
Width (overall) | 90" | 90" | 96" | 96" | 102" | 102" |
Depth (overall) | 34-1/2" | 34-1/2" | 34-1/2" | 34-1/2" | 34-1/2" | 34-1/2" |
Height (optional stainless top adds 1") | 25" | 27" | 25" | 27" | 25" | 27" |
Depth (overall, drawer fully extended) | 55-1/2" | 55-1/2" | 55-1/2" | 55-1/2" | 55-1/2" | 55-1/2" |
Pan capacity, 12" x 20" pans | 6 | 6 | 6 | 6 | 6 | 6 |
Voltage (dedicated circuit required) | 115 | 115 | 115 | 115 | 115 | 115 |
Amperage | 6.4 | 6.5 | 10.5 | 10.6 | 10.6 | 10.7 |
BTU Req. (90°F ambient, -15°F evaporator, 20' max. line length) | 1765 | 1780 | 1986 | 2102 | 2309 | 2417 |
Ship weight (lbs.) | 580 | 605 | 655 | 690 | 745 | 770 |
Ship volume (cu. ft.) | 57 | 62 | 61 | 66 | 65 | 70 |
Crated dimensions (38 1/2" D) | 27" H x 95-1/2" W | 29" H x 95-1/2" W | 27" H x 101-1/2" W | 29" H x 101-1/2" W | 27" H x 107-1/2" W | 29" H x 107-1/2" W |
Cabinet Exterior
Exterior sides and front are constructed of heavy gauge stainless steel. Exterior back and bottom are constructed of heavy gauge galvanized or optional stainless steel. Exterior dial thermometer. Square-cornered construction allows for continuous side-by-side line-up of sections. Cabinet is supported on heavy duty, adjustable 6" legs. Cabinet body is 100% CFC free, foamed-in-place polyurethane insulation.
Cabinet Interior
All heavy gauge stainless steel construction with coved corners. Heavy-duty stainless steel shelf standards and shelf clips for superior durability and corrosion resistance. One (1) chrome plated wire shelf per door opening. Each drawer has four, 2" diameter stainless steel ball-bearing rollers which travel on 14 gauge stainless steel slides. Door openings protected by impact-resistant PVC breaker strip.
Doors
All stainless steel construction with magnetic snap-in gasket. Door perimeters have built-in energy saving condensate heaters. One piece, stamped door handle with heavy-duty built-in security lock. In order to prevent damage to door during installation, doors are equipped with self-closing lift-off cam hinges for easy door removal. Doors stay open at 120 degrees for easy access to interior. Insulation is 100% CFC free foamed-in-place polyurethane.
Refrigeration
R-404a refrigerant. Thermostatic expansion valve for superior performance and efficiency, faster temperature recovery, less running time and lower energy consumption. Automatic defrost with fan delay to prevent hot air from being circulated in cabinet.Evaporator coil fully installed with pre-plumbed, stubbed out refrigeration and electrical lines to save time and expense during installation. Drain line exits on bottom at center of rear wall (other configurations available; please consult factory).
In line with its policy to continually improve its products, Utility Refrigerator reserves the right to change materials and specifications without notice.
